W12-6×1500 4-Roll Plate Bending Machine
Rolling range 2-6 mm | Upper roller diameter 160 mm | 4-Roll Plate Bending Machine
W12-6×1500
4-Roll Plate Bending Machine
W12 series features end pre-bending: sheet metal is loaded once and the plate end pre-bending plus the rolling of the workpiece are completed without turning the plate. The upper roll is main-driven; the lower and both side rolls are hydraulically driven, with computer-controlled, auto-levelling and on-screen displayed movement. The upper roll tail is fitted with a balancing device for easy removal of the rolled shell, and the machine has a safety interlock.
Key features
- One-pass loading for pre-bending and rolling
- Hydraulic lower/side roll movement, computer controlled with auto-levelling
- Hydraulic tilting bearing for easy shell removal
- 42CrMo forged steel rolls, surface hardened
- Mobile control console and safety interlock
Specifications
| Rolling range | 2-6 mm |
| Upper roller diameter | 160 mm |
| Lower roller diameter | 160 mm |
| Side roller diameter | 130 mm |
| Roller material | 42CrMo |
| Total power | 4 kW |
Applications: sheet metal fabrication, enclosures and cabinets, power and communication poles, automotive, elevators, kitchen equipment, lighting and medical equipment.
Customisation: bending length, tonnage, axis count and automation can be built to your workpiece. Send us your drawings for a quotation.
