GMZ20x3200 Hydraulic Guillotine Shear
Max. shearing thickness 20 mm | Max. shearing width 3200 mm | Hydraulic Guillotine Shear
GMZ20x3200
Hydraulic Guillotine Shear
GMZ series adopts an all-steel welded structure, stress-relieved by vibration for excellent rigidity. Three-point support rolling guides eliminate support clearance and improve cut quality. Blade clearance is adjusted automatically, quickly and accurately. Fitted with the E22 CNC and a well-known domestic hydraulic integrated system.
Key features
- All-steel welded structure, vibratory stress relieved
- Three-point support rolling guides for high cut quality
- Automatic blade clearance adjustment, fast and accurate
- E22 CNC with a well-known hydraulic integrated system
- Optional CNC back gauge, front supports and angle programming
Specifications
| Max. shearing thickness | 20 mm |
| Max. shearing width | 3200 mm |
| Distance between housings | 3520 mm |
| Strokes per minute | 10 spm |
| Shearing angle | 0.5-3 deg |
| Back gauge stroke | 20-800 mm |
| Main motor power | 30 kW |
| Hydraulic oil volume | 600 L |
| Overall length | 4100 mm |
| Overall width | 2100 mm |
| Overall height | 2600 mm |
| Weight | 14500 kg |
Applications: sheet metal fabrication, enclosures and cabinets, power and communication poles, automotive, elevators, kitchen equipment, lighting and medical equipment.
Customisation: bending length, tonnage, axis count and automation can be built to your workpiece. Send us your drawings for a quotation.
