GMPS-600/8000 Electro-Hydraulic Dual Servo Pump-Controlled Press Brake
Bending force 6000 kN | Bending length 8000 mm | Electro-Hydraulic Dual Servo Pump-Controlled Press Brake
GMPS-600/8000
Electro-Hydraulic Dual Servo Pump-Controlled Press Brake
GMPS series adopts a new integral or split main frame structure with high rigidity and toughness. The latest hybrid oil-electric drive system offers energy saving, high efficiency and low noise, greatly reducing working noise while improving efficiency and ensuring machine stability with a modern industrial design.
Key features
- Dual servo pump control with hybrid drive, significant power saving
- Integral or split frame for high rigidity
- Dual Y-axis synchronous control for high bending accuracy
- Low noise and low oil temperature, suitable for continuous production
- Optional CNC systems and axis configurations
Specifications
| Bending force | 6000 kN |
| Bending length | 8000 mm |
| Distance between housings | 7000 mm |
| Throat depth | 600 mm |
| Cylinder stroke | 400 mm |
| Open height | 800 mm |
| Main servo motor power | 21×2 kW |
| Max. speed – approach | 90 mm/s |
| Pressing speed | 0-7 mm/s |
| Return speed | 90 mm/s |
| Overall length | 8600 mm |
| Overall width | 3450 mm |
| Overall height | 4300 mm |
| Hydraulic oil volume | 2×300 L |
| Weight | 70000 kg |
Applications: sheet metal fabrication, enclosures and cabinets, power and communication poles, automotive, elevators, kitchen equipment, lighting and medical equipment.
Customisation: bending length, tonnage, axis count and automation can be built to your workpiece. Send us your drawings for a quotation.
